Electric Vehicle Electric Vehicle Charging Station Charger Floor Standing AC Charging Pile

ParameterPANELPanel TypeA+ TFT-LCD Panel 32 inchActive Area392*697mm (H*V)Resolution1920*1080 FHDAspect Ratio16:9Contrast Ratio1400:1Displaying Color1.07B (8-bit + Dithering)View Angle178°(H) / 178°(V)Response Time≤ 5msS-SystemPAL / NTSC / SECAMBacklightWLEDBrightness2000 nitsLife Expectance60000 HoursENVIRONMENTCooli

Featured Products


Panel TypeA+ TFT-LCD Panel 32 inch
Active Area392*697mm (H*V)
Resolution1920*1080 FHD
Aspect Ratio16:9
Contrast Ratio1400:1
Displaying Color1.07B (8-bit + Dithering)
View Angle178°(H) / 178°(V)
Response Time≤ 5ms
Brightness2000 nits
Life Expectance60000 Hours

Cooling SystemIP55 with Fan-cooling or
IP65 with Air-conditioner
Work Temp-20ºC to 55ºC
Storage Temp-25ºC to 60ºC
Work/Storage Humidity10% to 90%

Operating SystemAndroid, 2G RAM; 8G ROM or
Windows, 4G RAM; 128G SSD ( I3, I5, I7 optional )
Log ManagementSupportive to terminal log and playlist log
Power ModeTime-setting On or Off | Manual

MaterialGalvanized steel sheet (1.5mm) with zinc powder coating and fine grain powder triple coating
Protective Glass6MM Laminated and Tempered glass
I/O InterfaceWIFI, 4G, USB, SD Card, HDMI
Play ModePlug and play, Network(Remote)
Peripheral DeviceCamera, LED monochrome strip screen, Keyboard, Card reader, Speaker, Telephone, ReceiptPrinter, Finger-printer recognition, Bar code and OR code scanner ( optional )
Unit Carton DimensionTo be determined
Unit G.WTo be determined
AccessoriesRemote Control, AC Power Cord, Key, Rack, Instruction, Approval Certificate, Warranty Card

VoltageAC 100V - 240V
Standby≤ 3W
Output 7KW-22KW  2 guns/plugs in all (More Guns can be added)

Parameter of Charging gun
Mode 3Rated currentRated VoltageResistanceCharging cable
Type2 to Type216A 1Phase110V/250V680 ohm3*2.5mm²+2*0.5mm²
Type2 to Type216A 3Phase380V/450V680 ohm5*2.5mm²+2*0.5mm²
Type2 to Type232A 1Phase110V/250V220 ohm3*6mm²+2*0.5mm²
Type2 to Type232A 3Phase380V/450V220 ohm5*6mm²+2*0.5mm²
Type1 to Type216A110V/250V150/330 ohm3*2.5mm²+2*0.5mm²
Type1 to Type232A110V/250V150/330 ohm3*6mm²+2*0.5mm²

Charging specification:
  1. Please remove the protective cover, insert the Type 1/Type 2 Female into the charging port of the charging line vehicle, and the type 2 Male into the charging port of the charging pile.
  2. Ensure that the gun head is fully inserted into the socket, and the socket meets the national standard.
  3. Do not use the device to charging in rainy days.
  4. Do not submerge the control box in water.
  5. Do not step on, pull, fold or knot the cable.
  6. Do not place the charging cable near high temperature object when charging.
  7. Do not pl ace the device in the car or in a sealed space when charging.
  8. Do not operate the device in temperatures beyond its operating range of -25 °C to +50°C.
AC Charging Pile for Electric Car Electric Vehicle Charging Station Charger Floor Standing
Operating system
AC Charging Pile for Electric Car Electric Vehicle Charging Station Charger Floor Standing
With a great brightness of 2000 cd/m², the display clearly delivers contents and attracts public attention, which is the ultimate display for outdoor visibility.
2. HIGH PERFORMANCE & RELIABILITY -- Smart Brightness Control
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for effi cient power management.
3. HIGH PERFORMANCE & RELIABILITY -- Wide Operating Temperature Range
The panel offers superb reliability in a wide range of operating temperatures. The display can run normally in the work temprature from -40°C to +55°C.
Conformal Coating improves the long-term reliability of the main board and power board, protecting them from dust, iron powder, humidity, etc.
AC Charging Pile for Electric Car Electric Vehicle Charging Station Charger Floor Standing

More function can be added as below
AC Charging Pile for Electric Car Electric Vehicle Charging Station Charger Floor Standing
AC Charging Pile for Electric Car Electric Vehicle Charging Station Charger Floor Standing

CWD'S Certification
AC Charging Pile for Electric Car Electric Vehicle Charging Station Charger Floor Standing

Q1. What is your terms of packing?
A: Generally, we pack the goods neutrally (no brand name, no logo), however, if you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: 100% TT for sample
50% T/T, and 50% balance on delivery ready for bulk order.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU. Or according to your choices.

Q4. How about your delivery time?
A: It depends on the quantity as well as the date of order confirmation (by deposit). Generally our production time needs around 20 to 25 business days after confirming the drawing design. The time of goods leaving China to the destination address needs to be confirmed with freight forwarder.

Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can supply drawings according to the customization.

Q6. What is your sample policy?
A: We don't provide sample for free due to specialties of the products. Sample can be available if buyers pay the cost as well as freight. And the extra charge for sample will be refunded when bulk order comes.

Q7. Do you test all your goods before delivery?
A: Surely, that's an important way to make sure with quality. Our QC staffs will do their job very carefully. We will do the test, like watering test, waterproof test, radiation test, etc. Before delivery, we'll send you the testing results with sufficient videos and pictures.

Q8: What is your warranty policy?
A: 3 years (1 year for whole machine, 2 more years for hardware). Support in 48 hours.
