GB AC 63A/480V
1. Conform to the provisions and requirements of <Connection set for conductive charging of electric vehicles>GB/T20234.2-2015
2. Safety pins insulated head design to prevent accidental direct contact with staff
3. Have one or two PTC (PT1000) thermistors (can match with NTC or Temperature control switch)
4. Excellent protection performance, protection grade IP55 (working condition)
5. Adopted double color coating technology, personalized custom a variety of colors(Orange, blue, green,grey)
6. Reliable material,flame-etardant , pressure proof,wear-resisting,impact resistance ,high oil proof
7. Mechanical life: no-load plug> 10000
8. Impact of external force:can afford 1m drop and 2t vehicle run over pressure
1. The rated current : 32A,63A
2. The rated voltage: 440V
3. Insulation resistance:> 1000MΩ (DC500V)
4. Pins temperature rise: <50K
5. Withstand voltage: 2500V
6. Contact Resistance: 0.5mΩ Max
7. Shell material: thermoplastics, flame retardant grade UL94-0
8. Pin: Copper alloy, silver + top of the thermoplastic
9. Operating temperature: -30 ºC ~ +50 ºC
2. The rated voltage: 440V
3. Insulation resistance:> 1000MΩ (DC500V)
4. Pins temperature rise: <50K
5. Withstand voltage: 2500V
6. Contact Resistance: 0.5mΩ Max
7. Shell material: thermoplastics, flame retardant grade UL94-0
8. Pin: Copper alloy, silver + top of the thermoplastic
9. Operating temperature: -30 ºC ~ +50 ºC
1. Conform to the provisions and requirements of <Connection set for conductive charging of electric vehicles>GB/T20234.2-2015
2. Safety pins insulated head design to prevent accidental direct contact with staff
3. Have one or two PTC (PT1000) thermistors (can match with NTC or Temperature control switch)
4. Excellent protection performance, protection grade IP55 (working condition)
5. Adopted double color coating technology, personalized custom a variety of colors(Orange, blue, green,grey)
6. Reliable material,flame-etardant , pressure proof,wear-resisting,impact resistance ,high oil proof
7. Mechanical life: no-load plug> 10000
8. Impact of external force:can afford 1m drop and 2t vehicle run over pressure
