Mode3 Type2-Type2 16A/480V AC
1. The rated current : 16A,20A,32A
2. The rated voltage: 250V, 480V
3. Insulation resistance:> 1000MΩ (DC500V)
4. Pins temperature rise: <50K
5. Withstand voltage: 2500V
6. Contact impedance: 0.5mΩ Max
7. Operating temperature: -30 ºC ~ +50 ºC
8. Cable: 3×2.5mm²+2×0.5m
1. Conform to the provisions and requirements of IEC 62196-2 2016 2-IIe
2. Using riveting pressure process with none screw ,have a beautiful appearance. Hand-held design conform to the ergonomic principle , plug conveniently
3. XLPO for cable insulation prolonging the aging resistance life-span, TPU sheath improved the bending life and wear resistance of cable.
4. Excellent protection performance, protection grade achieved IP55 (working condition)
5. Adopted double color coating technology, personalized custom a variety of colors(Orange, blue, green,grey)
6. Mechanical life: no-load plug> 10000
