GB-AC-Z SOCKET
1. The rated current : 80A, 125A, 200A, 250A
2. The rated voltage : 750V/100V
3. Insulation resistance:> 1000MΩ (DC500V)
4. Pins temperature rise: <50K
5. Withstand voltage: 2500V
6. Contact impedance: 0.5mΩ Max
7. Shell material: thermoplastics, flame retardant grade UL94-0
1. Conform to the provisions and requirements of <Connection set for conductive charging of electric vehicles>GB/T20234.2-2015
2. Have a electromagnetic locking device(can match with hela lock),have functions of signal feedback
3. Have one or two PTC (PT1000) thermistor (can match with NTC or Temperature control switch
4. Beautiful appearance, automatically closed prevention cap with flip type,can install in front
5. Reliable material,flame-etardant, pressure proof, wear-resisting, impact resistance, high oil proof
6. Excellent protection performance, protection grade achieved IP55 (working condition)
1. The rated current : 80A, 125A, 200A, 250A
2. The rated voltage : 750V/100V
3. Insulation resistance:> 1000MΩ (DC500V)
4. Pins temperature rise: <50K
5. Withstand voltage: 2500V
6. Contact impedance: 0.5mΩ Max
7. Shell material: thermoplastics, flame retardant grade UL94-0
8. Contact-tube:copper alloy, silver-plate
9. Operating temperature: -30 ºC ~ +50 ºC1. Conform to the provisions and requirements of <Connection set for conductive charging of electric vehicles>GB/T20234.2-2015
2. Have a electromagnetic locking device(can match with hela lock),have functions of signal feedback
3. Have one or two PTC (PT1000) thermistor (can match with NTC or Temperature control switch
4. Beautiful appearance, automatically closed prevention cap with flip type,can install in front
5. Reliable material,flame-etardant, pressure proof, wear-resisting, impact resistance, high oil proof
6. Excellent protection performance, protection grade achieved IP55 (working condition)
7. Mechanical life: no-load plug> 10000
8. Coupled insertion force: <100N
